SEEEDStudio XIAO nRF52840 Bluetooth+Wio SX1262 LoRa Meshtastic Modules

Description:

Seeed Studio XIAO Series is incredibly compact (only 22.86 x 17.78mm), making it easy to integrate into small devices without compromising any performance.Xiao nRF52840 combined with Wio SX1262 is a powerful Microcontroller with Long-Range Communication  dev board for a wide range IoT devices.Seeed Studio offers open-source hardware and software for these modules, allowing users to customize and expand functionality easily. It encourages innovation and prototyping.and perfect to flashing Meshtastic&Meshcore.

Specification：

Firmware:default flash meshtastic

XIAO nRF52840 Bluetooth：Nordic nRF52840 5.0 BLE

Wio-SX1262 LoRa:Semtech SX1262

LoRa Band:862-930MHz

Antenna:2Dbi 868MHz or 915MHz

Interface:Type C

Charging voltage (Type-C/5V,Battery/3.7V)

Charging battery current: 50mA/100mA

Standby power consumption: <5uA

Working Temperature:-40°C ~ 65°C

Dimensions:21 x 17.8mm

Why Choose XIAO nRF52840+Wio SX1262 from TWOPIGEON?

TWOPIGEON and SEEEDStudio have a deep collaboration and developed several projects.

Most the projects are all based on the XIAO nRF52840+Wio SX1262 LoRa modules. We are very familiar with the Bluetooth+LoRa module,

And connect with the antenna (2dBi) that we have inspection. Buyer unbox and using if for Meshtastic mesh APP.Of couse You can also flash the meshcore too.All the SEEEDStudio product on TWOPIGEON are original and enjoy 2 years warranty.
